KS8 Wheelchair under floor lift

  • System: Hydraulic
  • Accessibility: Ramp / Lift
  • Opening type: Elevator
  • Compatibility: Coaches
KS8 Wheelchair under floor lift KS8 Wheelchair under floor lift
KS8 Wheelchair under floor lift KS8 Wheelchair under floor lift

/ Description and characteristics

  • Hydraulic lift for motor coaches. Lifts up to 1882mm.
  • Designed to be placed under floor of the vehicle placed on the wheel arch or in a luggage compartment.
  • Semiautomatic: Automatic barriers / manual handrails.
  • Electronic control with fault analysis by blinking light. (CAN bus system)
  • Robust and compact design for minimal space requirements.
  • Stable and secure platform.
  • 2 years warranty (see service manual for details).
  • All movements can be manually operated, in case of lack of power supply.
.PDF Download file

/ Advantages

  • Easy to install. Hydraulic unit is integrated in the lift, allowing a plug-and-play connection.
  • Easy operation by means of a hand-held control.
  • Optional support guides to extract the lift and facilitate maintenance tasks.

/ Safety

  • High protective handrails.
  • Detector of unfolded handrails.
  • Automatic inner roll stop (bridging device).
  • Automatic hydraulic outer stop barrier for maximal safety.
  • Audible warning device.
  • Pressure device to detect platform occupancy at stowing.

/ Technical data

  • Standard version Technical features
  • Maximal load: 350 kg
  • Lift standard weight: 464 kg
  • High resistance steel
  • Power supply: 24V / max 50A
  • According to Regulations: R107, DDA
  • US version Technical features
  • Maximal load: 272 kg (600 lb)
  • Lift standard weight: 464 kg (1023 lb)
  • High resistance steel
  • Power supply: 24V / max 50A
  • According to Regulations: NHTSA 403/404 Compliant DOT_Public Use
  • Optional: supply of threshold warning system through acoustic and lighting alert.
